iDRAC - Virtual Media 사용하기 원격 Windows 서버에 로컬 폴더의 파일들을 이동하고 싶은데, 서비스 네트워크를 이용할 수 없어서 난감한 상황에... - 로컬 데스크탑에 Dell이란 폴더 하위에 전송하고 싶은 파일이 위치해 있음 - iDRAC의 Virtual Console 메뉴에서 "Create Image ..." 항목 선택 .img 또는 .iso로 쉽게 생성이 가능하다. (HPE는 .iso가 편한데, Dell은 .img가 편한듯 싶은 ... 느낌 아닌 느낌 ...) 생성이 완료 되면, "Map Removable Disk ..." 항목을 선택하여, 생성된 이미지를 마운트 한다. 친절히도 생성된 이미지를 List up 해준다. 안보이면 찾아봐야 할 듯 ... 원격 서버에서 관련 파일들을 접근해 볼 수 있다. 2019. 8. 15.
How to restore the service tag using Easy Restore? Dell PowerEdge 13G/14G : How to restore the service tag using Easy Restore? 1. Where the service profile is stored? Easy Restore Storage is part of the server front panel or the management riser (for blade servers) 2. What information is stored? --------------------------------------- System Service Tag All licenses UEFI diagnostics System configuration settings (BIOS, iDRAC & NIC) OEM ID (Perso.. 2019. 7. 31.
Windows 환경에서 DSET 취합 DSET 3.7.0 for Windows (final version) Dell_DSET_3.7.0.219.zip Windows 버전의 경우 마법사가 구동되어 매우 직관적이기에 사용이 쉬움. How to use DSET 2.2 in Windows https://www.dell.com/support/article/us/en/04/sln292237/how-to-use-dset-22-in-windows?lang=en 2018. 7. 2.
Dell PowerEdge 12G Server - System Board 교체 후 Service Tag 변경 1. Support Live Image Download e.g) Dell Support Live Image Version 2.2 http://www.dell.com/support/home/kr/ko/krdhs1/drivers/driversdetails?driverId=CWF92 SLI22_A00.iso Dell Asset Tag Utility for Dell 9G-12G servers. * When Dos-Based Asset Tag for 12G option is selected, an error message "Insert a Disk 2" is displayed. Ignore the error message and proceed. 2. Boot from Support Live Image 3. Sel.. 2017. 10. 27.
Linux 환경에서 DSET 취합 PowerEdge 운영 중 오류 발생 등으로 하드웨어 점검이 필요한 때, 로그 취합이 필요할 수 있는데, 유용한 툴이 DSET이다. Dell 공식 Website에서 DSET을 다운로드 받아서 실행하면 현재 운영 중인 시스템의 정보를 취합할 수 있다. 1. DSET 패키지 다운로드 DSET 3.7.0 for Linux (final version) dell-dset-lx32-3.7.0.219.bin dell-dset-lx64-3.7.0.219.bin 2. 실행 가능하도록 권한 변경 # chmod +x dell-dset-lx64-3.7.0.219.bin 3. DSET명령 수행 # ./dell-dset-lx64-3.7.0.219.bin 2) Create a One-Time Local System DSET Rep.. 2017. 10. 26.
2950/WS2008 R2 install with SBUU 2.4.1294 PowerEdge 2950 장비에 Windows 2008 R2 Server OS 설치해보기 오랜만에 했더니 많이 헤메였다는 ... SBUU 미디어로 부팅 언어는 머 영문 밖에 택할 수 있는것이 ... EULA 하고 기존에 볼륨이 구성되어 있는데, 구성이 안되어 있다고 나오는건 뭐징 ..? 다시 볼륨 구성하고, 설치할 OS 선택하고, 설치 시작하기! 설치 과정에 질의가 친절 친절! 2017. 9. 8.
R730/VLT0204-voltage is outside of range. 경험 예기치 않은 시스템 다운을 겪고, 부팅에 실패한 상황에, 전면 LED 패널에 "The system board voltage is outside of range." 메시지 출력 Model: R730 System Event log -------------------VLT0204The system board BP1 5V PG voltage is outside of range.The system board fail-safe voltage is outside of range.--------------------------------------- 전원 관련 모듈 점검이 필요한 상황- PSU- SB- Backplane Board Urgent: The system board BP1 5V PG voltage is out.. 2017. 2. 20.
PE/Disk Spare 정보 확인 Disk 정보를 열람.# omreport storage pdisk controller=0List of Physical Disks on Controller PERC 6/i Integrated (Embedded) Controller PERC 6/i Integrated (Embedded)ID : 0:0:0Status : OkName : Physical Disk 0:0:0State : OnlinePower Status : Not ApplicableBus Protocol : SASMedia : HDDPart of Cache Pool : Not ApplicableRemaining Rated Write Endurance : Not ApplicableFailure Predicted : YesRevision : HT64.. 2016. 9. 19.
Memory - UDIMM vs. RDIMM vs. LRDIMM vs. HDIMM UDIMM ECC (Unbuffered or Unregistered DIMM): 저렴한 가격 대신, 8 bit (x8) DRAM 만을 사용하고 최대 2 Rank까지 확장할 수 있는 메모리 타입 지원 용량을 저전력으로 유지함. 채널 당 2개 DIMM만 사용이 가능함. 오류를 줄이기 위해 저용량만을 지원하며 버퍼나 레지스터가 없어 빠른 응답률을 갖는다. RDIMM (Registered DIMM): 메모리에 버퍼(레지스터)를 추가하여 DIMM의 주소와 명령 신호를 관리한다. x8 외에 x4 DRAM을 지원하고, DIMMs당 최대 4 Rank 혹은 채널 당 3개 DIMM까지 확장할 수 있는 메모리 타입 보다 강력한 R.A.S(Reliability, Availability, Serviceability - 에러 보.. 2014. 12. 27.
