Dell PowerEdge 13G/14G : How to restore the service tag using Easy Restore?
1. Where the service profile is stored?
Easy Restore Storage is part of the server front panel or the management riser (for blade servers)
2. What information is stored?
---------------------------------------
System Service Tag
All licenses
UEFI diagnostics
System configuration settings (BIOS, iDRAC & NIC)
OEM ID (Personality Module)
---------------------------------------
3. How to proceed to a full server profile backup?
Customers can still choose to do the full system backup with iDRAC8 as they do with iDRAC6 and iDRAC7 as this solution will back up and restore the actual firmware versions in addition to the hardware settings. Easy Restore does not carry the firmware drivers due to size limitations.
4. Restoring the service tag using Easy Restore
1. Turn on the system.
If BIOS detects a new system board, and if the service tag is present in the backup flash device, BIOS displays the service tag, the status of the license, and the UEFI Diagnostics version.
Do one of the following:
Press Y to restore the service tag, license, and diagnostics information.
Press N to navigate to the Lifecycle Controller based restore options.
Press to restore data from a previously created Hardware Server Profile.
After the restore process is complete, BIOS prompts to restore the system configuration data.
Do one of the following:
Press Y to restore the system configuration data.
Press N to use the default configuration settings.
After the restore process is complete, the system reboots.
5. Manually setting the service tag when the Easy Restore doesn't work
If Easy Restore fails to restore the Service Tag, use the System Setup to manually set the Service Tag. This method works for 13G & 14G PowerEdge servers
Turn on the system.
Press F2 to enter System Setup.
Click Service Tag Settings.
Enter the Service Tag.
Click Ok.
---------------------------------------
Important:
- The Service Tag can only be entered when the Service Tag field is empty.
- After the Service Tag is entered, it cannot be updated or changed. Ensure that you enter the correct Service Tag.
- Incorrect service tag entry will require a system board replacement to input the correct service tag.
---------------------------------------
